660nm laser
The 660 nm laser of CRYLINK is a 660nm Microchip laser. These series of lasers are mainly used in Lidar, Spectroscopy, Laser display, Photodynamic Medicine, Environmental monitoring, and Laser remote sensing.
660nm Microchip Laser System of ML Series
ML series of micro laser is a passive Q-switched solid laser based on a semiconductor pump. The laser pulse is pure and tailless, the single pulse energy is stable, and the beam quality is good. Integrated design of semiconductor pump module and laser crystal, compact laser head convenient installation and integration, the system supports internal and external triggers. The fully sealed module inside the laser head of this series of products can be used by customers for secondary development and application.
| Model | CL660-0.1KHz-10μJ-ML001 | CL660-1KHz-6μJ-ML002 |
| Wavelength(nm) | 660 | |
| Repetition frequency (KHz) | 0.1* | 1* |
| Average power(mW) | 1 | 6 |
| Output energy(uJ) | 10 | 6 |
| Pulse width (ps) | 2000 | |
| Power stability (8h) | ±3% | |
| Beam mode | TEM00 | |
| Full-angle divergence angle Typ. (Mrad) level @ 1/e2 | 6 | |
| Vertical @ 1 / e2 | 6 | |
| Polarization characteristics | ＞100:1 | |
| System power consumption（W） | ≤20 | ≤45 |
| Power input | 100-240 VAC,50/60Hz | |
| Control interface | RS232、USB | |
| Power supply size (W × H × L, mm) | 168×88×140 | |
| Laser head size (W × H × L, mm) | 45×30×120 | |
| Working temperature (℃) | 15-35 | |
| Storage temperature (℃) | 0-60 | |
| 1.Customized internal beam expansion function to meet the requirements of small divergence angle (less than 2mrad) | ||
- The pulse width can reach 2.5ns
- Pulse energy up to 50 μ J
- Maximum repetition rate up to 2KHz
- Beam mode is TEM00
- Fully sealed design, high reliability
- High polarization direction stability
- Lidar
- Spectroscopy
- Laser display
- Photodynamic Medicine
- Environmental monitoring
- Laser remote sensing
