Temperature Control Module

The electronics research and development team has 15 research and development engineers, 6 of whom have more than 5 years of laser electronics design experience. The team is young and passionate, with a rigorous and solid style and dare to challenge innovation. The team’s capabilities include hardware design, embedded software design, FPGA development, and host computer software development. It has rich technical accumulation, undertakes and completes a number of vertical and horizontal projects, and undertakes more than 20 projects per year on average. The project covers solid-state lasers, fiber lasers, and laser applications such as laser communications, laser wind measurement, and gas aerosol detection. Technical accumulation includes: high-precision, low noise, high power and other temperature control, LD drive technology; resonance detection, PDH, saturation absorption, MTS and other laser frequency stabilization technologies; PD, PMT, APD and other photoelectric detection technologies; laser system timing and Signal editing; data acquisition and processing; system integration.

  • Compact design and expandable;
  • Provide supporting software and open communication interface for easy use and secondary development;
  • The temperature control accuracy is stable, and the digital temperature control accuracy can reach ± 0.0025 ℃;
  • Accept customization

Conventional Tec temperature control module

Supply voltage12VDC
TEC compatibility3-12V,Maximum 10A current available
Temperature control accuracy±0.01℃
Temperature setting range10-55℃,Effective adjustment step 0.02 ℃
Circuit board efficiencyGreater than 80%
Communication InterfaceRS232/RS422

High precision digital Tec temperature control module

Supply voltage12VDC
TEC compatibility3-12V,Maximum 3A current available
Temperature control accuracy±0.0025℃
Temperature setting range15-45℃,Effective adjustment step 0.002 ℃
Circuit board efficiencyGreater than 80%
Communication InterfaceRS232/RS422

High precision linear Tec temperature control module

Supply voltage5VDC
TEC compatibility3-5V,Maximum 3A current available
Temperature control accuracy±0.001℃
Temperature setting range15-45℃,Effective adjustment step 0.002 ℃
Circuit board efficiencyGreater than 50%
Communication InterfaceRS232/RS422
